Extreme S Silent V/D 90L Medical Oil-Free Compressor
$0.00
The NARDI COMPRESSORI MEDICAL range is engineered specifically for dental and medical environments where clean, dry air is essential. Each compressor features an internally coated air tank with corrosion-resistant epoxy powder and is equipped with a high-performance dryer to eliminate moisture and ensure optimal air quality. Antibacterial filters are available to meet strict international health standards.
Built using high-quality materials, these compressors are quiet, reliable, and durable. All models in the MEDICAL line are certified as Class IIA medical devices and officially recognized by the Italian Ministry of Health.
EXTREME SD 90L – Super-Silenced, Oil-Free Medical Compressor
The EXTREME SD 90L Medical is a compact, oil-free compressor ideal for noise-sensitive areas such as dental clinics, chemical laboratories, and medical facilities. It features a 90-liter air receiver with internal anti-corrosion coating and a fully enclosed cabinet with a forced air cooling system for efficient heat management. The Extreme SV is the standard model. The Extreme SD comes equipped with the D400 Dryer.
This model includes a long-life pump unit, integrated adjustable pressure regulator, and can be optionally equipped with a desiccant dryer manufactured by NARDI COMPRESSORI. Designed for performance and longevity, the EXTREME SD 90L delivers reliable, moisture-free air in the most demanding medical environments. With its 2.5 horsepower motor, the 90L delivers up to 6.7 CFM at 114 psi while only generating 62 dB of noise.
[Click to Download Medical Compressor Catalog]
Request a Quote for More Information
Click the REQUEST A QUOTE button to discuss your specific needs and get detailed information on optional equipment such as soft start, oil pump, upgraded filtering system, dual-pressure fill option, condensate collector, extra-large separators, air quality analyzers, and more.
Quantity
Snail trail
Name
SKU
Description
Title
Description
SKU
Title
SKU
Title
Technical Specifications
Model | Dryer | Charging Rate (cfm) | Maximum psi | Intake (cfm) | Stg / Cyl | Power · Phase | Sound (dB) | Weight (lb) | Dimensions (inches) |
|---|---|---|---|---|---|---|---|---|---|
Hookah Pro | No | -- | 145 | 8.5 | 2 | 1.5hp · 1Ø | 72 | 53 | 19.7L x 11.8W x 16.5H” |
Nardi ONE 85 | No | 30 | 6000 | -- | 4 | 25hp · 3Ø | 2866 | 90.6L x 34.1W x 71.7H" | |
Nardi ONE 68 | No | 24.0 | 6000 | -- | 4 | 20hp · 3Ø | 2646 | 90.6L x 34.1W x 71.7H" | |
Nardi ONE 60/4 | No | 21.2 | 6000 | -- | 4 | 15hp · 3Ø | 2646 | 90.6L x 34.1W x 71.7H" | |
Nardi ONE 60 | No | 21.2 | 6000 | -- | 3 | 15hp · 3Ø | 2601 | 90.6L x 34.1W x 71.7H" | |
Nardi ONE 50 | No | 17.7 | 6000 | -- | 3 | 15hp · 3Ø | 2513 | 90.6L x 34.1W x 71.7H" | |
Extreme 5G Fibre | No | -- | 145 | 9.5 | 2 | 3hp Gas | 85 | 56 | 20.1L x 12.2W x 16.5H" |
Extreme 5E Fibre | No | -- | 145 | 9.5 | 2 | 1.5hp · 1Ø | 72 | 54 | 20.1L x 11.4W x 15.8H" |
Extreme 2 50L 2hp | No | -- | 114 | 12.4 | 2 | 2hp · 1Ø | 67 | 103 | 23.2L x 16.9W x 33.5H" |
Extreme 2 50L 1.5hp | No | -- | 114 | 8.5 | 2 | 1.5hp · 1Ø | 66 | 99 | 23.2L x 16.9W x 33.5H" |
Extreme 2 50L 0.75hp | No | -- | 114 | 7 | 2 | .75hp · 1Ø | 66 | 92.5 | 23.2L x 16.9W x 33.5H" |
Extreme 2 25L 2hp | No | -- | 114 | 12.4 | 2 | 2hp · 1Ø | 67 | 90 | 19.7L x 16.9W x 33.5H" |
Extreme 2 25L 1.5hp | No | -- | 114 | 8.5 | 2 | 1.5hp · 1Ø | 66 | 85 | 19.7L x 16.9W x 33.5H" |
Extreme 2 25L 0.75hp | No | -- | 114 | 7 | 2 | .75hp · 1Ø | 66 | 79.5 | 19.7L x 16.9W x 33.5H" |
Silverstone 24V 350W | No | -- | 114 | 4.2 | 1 | 350W · 24V | 74 | 15.4 | 13L x 5.9W x 9W" |
Extreme 1C 25L 1.5hp | No | -- | 145 | 8.5 | 2 | 1.5hp · 1Ø | 72 | 73 | 21.3L x 23.6W x 32.7H" |
Extreme 1C 25L 2hp 1400 | No | -- | 145 | 12.4 | 2 | 2hp · 1Ø | 73 | 85 | 21.3L x 23.6W x 32.7H" |
Extreme 1C 25L 2hp 2800 | No | -- | 145 | 14.1 | 2 | 2hp · 1Ø | 83 | 80 | 21.3L x 23.6W x 32.7H" |
Extreme MPR 500L 6.0 | D600 | 18 | 116 | 42.4 | 8 | 6hp · 3Ø | 74 | 547 | 76.7L x 36.6W x 43.3H" |
Extreme MPR 500L 9.0 | D600 | 27 | 116 | 63.6 | 12 | 9hp · 3Ø | 75 | 650 | 76.7L x 36.6W x 43.3H" |
Extreme MPR 270L 3.0 | D600 | 8.8 | 114 | 21.2 | 4 | 3hp · 3Ø | 73 | 287 | 63L x 36.6W x 34.3H" |
Extreme MPR 270L 6.0 | D600 | 18 | 114 | 42.4 | 8 | 6hp · 3Ø | 74 | 425 | 63L x 36.6W x 34.3H" |
Extreme MPR 270L 9.0 | D600 | 27 | 114 | 63.6 | 12 | 9hp · 3Ø | 75 | 530 | 63L x 36.6W x 34.3H" |
Extreme SR 2.0 | D600 | 4.5 | 114 | 12.4 | 2 | 2hp · 1Ø | 64 | 173 | 28.0L x 17.3W x 29.9H" |
Extreme 4R 90L 2.0 1Ø | D600 | 4.5 | 114 | 12.4 | 2 | 2hp · 1Ø | 73 | 167 | 43.3L x 23.2W x 31.9H" |
Extreme 4R 90L 2.5 1Ø | D600 | 6.7 | 114 | 17 | 4 | 2.5hp · 1Ø | 73 | 189 | 43.3L x 23.2W x 31.9H" |
Extreme 4R 90L 3.0 3Ø | D600 | 8.8 | 114 | 21.2 | 4 | 3hp · 3Ø | 73 | 194 | 43.3L x 23.2W x 31.9H" |
Extreme 3R 2.0 | D600 | 4.5 | 114 | 12.4 | 2 | 2hp · 1Ø | 73 | 112 | 34.7L x 17.3W x 26.8H" |
Extreme 2R 3.0 3Ø | D600 | 8.8 | 114 | 21.2 | 4 | 3hp · 3Ø | 73 | 169 | 25.2L x 17.7W x 55.1H" |
Extreme 2R 3.0 1Ø | D600 | 17.0 | 114 | 6.7 | 4 | 3hp · 1Ø | 73 | 165 | 25.2L x 17.7W x 55.1H" |
Extreme 2R 2.0 1Ø | D600 | 12.4 | 114 | 4.5 | 2 | 2hp · 1Ø | 73 | 145 | 23L x 16.9W x 55.1H" |
Extreme 2R 2.0 1Ø | D600 | 4.5 | 114 | 12.4 | 2 | 2hp · 1Ø | 73 | 112 | 23L x 16.9W x 32.7H" |
Extreme 2R 3.0 1Ø | D600 | 6.7 | 114 | 17.0 | 4 | 3hp · 1Ø | 73 | 132 | 25.2L x 17.7W x 35H" |
Extreme 2R 3.0 3Ø | D600 | 8.8 | 114 | 21.2 | 4 | 3hp · 3Ø | 73 | 136 | 25.2L x 17.7W x 35H" |
Shooting D 100 | -- | 3.5 | 4700 | -- | 4 | 4.7hp Diesel | 84 | 135 | 32.3L x 14.6W x 19.7H" |
Esprit 3 60 500W 24V | No | -- | 145 | 7.9 | 2 | 24V (500W) | 62 | 32 | 18.5L x 8.7W x 15.8H" |
Esprit 3 60 600W 12V | No | -- | 145 | 7.9 | 2 | 12V (600W) | 62 | 32 | 18.5L x 8.7W x 15.8H" |
Esprit 3 60 500W 12V | No | -- | 145 | 6.4 | 2 | 12V (500W) | 58 | 27 | 18.5L x 8.7W x 15.8H" |
Sany+Air | No | -- | 30 | 3.5 | 1 | .5hp · 1Ø | 72 | 18 | 19.7L x 6.7W x 12.2H" |
Extreme MPD 500L 9hp | D600 | -- | 145 | 63.6 | 12 | 9hp · 3Ø | 75 | 650 | 76.7L x 36.6W x 43.3H" |
Extreme MPD 500L 6hp | D600 | -- | 145 | 42.4 | 8 | 6hp · 3Ø | 74 | 547 | 76.7L x 36.6W x 43.3H" |
Extreme MPD 270L 3hp | D600 | -- | 145 | 21.2 | 4 | 3hp · 3Ø | 73 | 287 | 63L x 36.6W x 34.3H" |
Extreme MPD 270L 6hp | D600 | -- | 145 | 42.4 | 8 | 6hp · 3Ø | 74 | 425 | 63L x 36.6W x 34.3H" |
Extreme MPD 270L 9hp | D600 | -- | 145 | 63.6 | 12 | 9hp · 3Ø | 75 | 530 | 63L x 36.6W x 34.3H" |
Extreme 2D 50L 1.5 | Yes | -- | 114 | 8.5 | 2 | 1.5hp · 1Ø | 72 | 106 | 23L x 16.9W x 32.7H" |
Extreme 2D 50L 2.5 | Yes | -- | 114 | 6.7 | 2 | 2.5hp · 1Ø | 73 | 132 | 23L x 16.9W x 32.7H" |
Extreme 2D 50L 2.0 | Yes | -- | 114 | 12.4 | 2 | 2hp · 1Ø | 73 | 112 | 23L x 16.9W x 32.7H" |
Extreme 2D 25L 2.0 | Yes | -- | 114 | 4.5 | 2 | 2hp · 1Ø | 72 | 97 | 23L x 16.9W x 26H" |
Extreme 2V 25L 2.0 | No | -- | 114 | 4.5 | 2 | 2hp · 1Ø | 73 | 78 | 18.1L x 16.9W x 26H" |
Extreme 2D 25L 1.5 | Yes | -- | 114 | 3.5 | 2 | 1.5hp · 1Ø | 72 | 91 | 23L x 16.9W x 26H" |
Extreme 2V 25L 1.5 | No | -- | 114 | 3.5 | 2 | 1.5hp · 1Ø | 72 | 73 | 18.1L x 16.9W x 26H" |
Pacific M Nitrox 30 | No | 10.6 | 6000 | -- | 4 | 7.5hp · 1/3Ø | 68 | 674 | 29.5L x 42.5W x 52.8H" |
Pacific MX 60 Nitrox Silenced | No | 21.2 | 6000 | -- | 4 | 15hp · 3Ø | 72 | 1080 | 33.9L x 59.1W x 68.5H" |
Pacific MX 60 Nitrox Open | No | 21.2 | 6000 | -- | 4 | 15hp · 3Ø | 72 | 1080 | 33.9L x 51.2W x 68.5H" |
Extreme MPD 500L 9.0 | D600 | -- | 145 | 63.6 | 12 | 9hp · 3Ø | 75 | 650 | 76.7L x 36.6W x 43.3H" |
Extreme MPD 500L 6.0 | D600 | -- | 145 | 42.4 | 8 | 6hp · 3Ø | 74 | 547 | 76.7L x 36.6W x 43.3H" |
Extreme MPV 500L 9.0 | No | -- | 145 | 63.6 | 12 | 9hp · 3Ø | 75 | 558 | 76.7L x 25.2W x 43.3H" |
Extreme MPV 500L 6.0 | No | -- | 145 | 42.4 | 8 | 6hp · 3Ø | 74 | 485 | 76.7L x 25.2W x 43.3H" |
Extreme SD 50L 2.0 | D400 | -- | 114 | 12.4 | 2 | 2hp · 1Ø | 60 | 210 | 33.5L x 19.7W x 32.2H" |
Extreme SD 50L 1.5 | D400 | -- | 114 | 8.5 | 2 | 1.5hp · 1Ø | 59 | 199 | 33.5L x 19.7W x 32.2H" |
Extreme SV 50L 2.0 | No | -- | 114 | 12.4 | 2 | 2hp · 1Ø | 60 | 195 | 28.3L x 19.7W x 32.2H" |
Extreme SV 50L 1.5 | No | -- | 114 | 8.5 | 2 | 1.5hp · 1Ø | 59 | 183 | 28.3L x 19.7W x 32.2H" |
Extreme MPD 270L 9.0 | D600 | -- | 145 | 63.6 | 12 | 9hp · 3Ø | 75 | 530 | 63L x 36.6W x 34.3H" |
Extreme MPD 270L 6.0 | D600 | -- | 145 | 42.4 | 8 | 6hp · 3Ø | 74 | 425 | 63L x 36.6W x 34.3H" |
Extreme MPD 270L 3.0 | D600 | -- | 145 | 21.2 | 4 | 3hp · 3Ø | 73 | 287 | 63L x 36.6W x 34.3H" |
Extreme MPV 270L 9.0 | No | -- | 145 | 63.6 | 12 | 9hp · 3Ø | 75 | 436 | 39.3L x 25.2W x 34.3H" |
Extreme MPV 270L 6.0 | No | -- | 145 | 42.4 | 8 | 6hp · 3Ø | 74 | 364 | 39.3L x 25.2W x 34.3H" |
Extreme MPV 270L 3.0 | No | -- | 145 | 21.2 | 4 | 3hp · 3Ø | 73 | 255 | 39.3L x 25.2W x 34.3H" |
Extreme SD 90L 3.0 3Ø | D600 | -- | 145 | 11 | 4 | 3hp · 3Ø | 62 | 369 | 33.8L x 22W x 43.3H" |
Extreme SD 90L 3.0 1Ø | D600 | -- | 145 | 8.5 | 4 | 3hp · 1Ø | 62 | 369 | 33.8L x 22W x 43.3H" |
Extreme SV 90L 3.0 3Ø | No | -- | 145 | 11 | 4 | 3hp · 3Ø | 62 | 342 | 33.8L x 22W x 40.2H" |
Extreme SV 90L 3.0 1Ø | No | -- | 145 | 8.5 | 4 | 3hp · 1Ø | 62 | 342 | 33.8L x 22W x 40.2H" |
Extreme 4D 90L 3.0 3Ø | D600 | -- | 145 | 21.2 | 4 | 3hp · 3Ø | 73 | 170 | 43.3L x 21.3W x 31.9H" |
Extreme 4D 90L 3.0 1Ø | D600 | -- | 145 | 17 | 4 | 3hp · 1Ø | 73 | 167 | 43.3L x 21.3W x 31.9H" |
Extreme 4V 90L 3.0 3Ø | No | -- | 145 | 21.2 | 4 | 3hp · 3Ø | 73 | 170 | 43.3L x 21.3W x 31.9H" |
Extreme 4V 90L 3.0 1Ø | No | -- | 145 | 17 | 4 | 3hp · 1Ø | 73 | 147 | 43.3L x 21.3W x 31.9H" |
Extreme 2D 90L 3.0 3Ø | D600 | -- | 145 | 21.2 | 4 | 3hp · 3Ø | 77 | 170 | 29.1L x 17.7W x 55.1H" |
Extreme 2D 90L 3.0 1Ø | D600 | -- | 145 | 17 | 4 | 3hp · 1Ø | 77 | 170 | 29.1L x 17.7W x 55.1H" |
Extreme 2V 90L 3.0 3Ø | No | -- | 145 | 21.2 | 4 | 3hp · 3Ø | 73 | 152 | 25.1L x 17.7W x 55.1H" |
Extreme 2V 90L 3.0 1Ø | No | -- | 145 | 17 | 4 | 3hp · 1Ø | 73 | 152 | 25.1L x 17.7W x 55.1H" |
Extreme SD 90L 2.5 | D400 | -- | 114 | 17 | 4 | 2.5hp · 1Ø | 62 | 340 | 37.8L x 22.0W x 40.2H" |
Extreme SV 90L 2.5 | No | -- | 114 | 17 | 4 | 2.5hp · 1Ø | 62 | 340 | 37.8L x 22.0W x 40.2H" |
Extreme SD 50L 2.0 | D400 | -- | 114 | 12.4 | 2 | 2hp · 1Ø | 60 | 210 | 33.5L x 19.7W x 32.3H" |
Extreme SD 50L 1.5 | D400 | -- | 114 | 8.5 | 2 | 1.5hp · 1Ø | 59 | 199 | 33.5L x 19.7W x 32.3H" |
Extreme SV 50L 2.0 | No | -- | 114 | 12.4 | 2 | 2hp · 1Ø | 60 | 195 | 29.3L x 19.7W x 32.3H" |
Extreme SV 50L 1.5 | No | -- | 114 | 8.5 | 2 | 1.5hp · 1Ø | 59 | 183 | 29.3L x 19.7W x 32.3H" |
Extreme SD 30L 2.0 | D400 | -- | 114 | 12.4 | 2 | 2hp · 1Ø | 62 | 173 | 28.0L x 17.3W x 29.9H" |
Extreme SD 30L 1.5 | D400 | -- | 114 | 8.5 | 2 | 1.5hp · 1Ø | 61 | 165 | 28.0L x 17.3W x 29.9H" |
Extreme SV 30L 2.0 | No | -- | 114 | 12.4 | 2 | 2hp · 1Ø | 62 | 158 | 25.6L x 17.3W x 29.9H" |
Extreme SV 30L 1.5 | No | -- | 114 | 8.5 | 2 | 1.5hp · 1Ø | 61 | 150 | 25.6L x 17.3W x 29.9H" |
Extreme 2V 50L 2hp | No | -- | 114 | 12.4 | 2 | 2hp · 1Ø | 67 | 103 | 22.8L x 16.9W x 38.6H" |
Extreme 2D SIL 25L 2.0 | D400 | -- | 114 | 1.2 | 2 | 2hp · 1Ø | 67 | 106 | 27.6L x 16.9W x 30.7H" |
Extreme 3D 50L 2.0 | D400 | 4.5 | 114 | 12.4 | 2 | 2hp · 1Ø | 73 | 112 | 33L x 17.3W x 26.8H" |
Extreme 3D 50L 1.5 | D400 | 3.5 | 114 | 8.5 | 2 | 1.5hp · 1Ø | 72 | 105 | 33L x 17.3W x 26.8H" |
Extreme 3V 50L 2.0 | No | 4.5 | 114 | 12.4 | 2 | 2hp · 1Ø | 73 | 95 | 33L x 12.2W x 26.8H" |
Extreme 3V 50L 1.5 | No | 3.5 | 114 | 8.5 | 2 | 1.5hp · 1Ø | 72 | 88 | 33L x 12.2W x 26.8H" |
Extreme 4D 90L 3hp | Yes | 8.8 | 145 | 21.2 | 4 | 3hp · 3Ø | 73 | 170 | 43.3L x 23.2W x 31.9H" |
Extreme 4D 90L 3hp | Yes | 6.7 | 145 | 17 | 4 | 3hp · 1Ø | 73 | 167 | 43.3L x 23.2W x 31.9H" |
Extreme 4V 90L 3hp | No | 8.8 | 145 | 21.2 | 4 | 3hp · 3Ø | 73 | 170 | 43.3L x 21.3W x 31.9H" |
Extreme 4V 90L 3hp | No | 6.7 | 145 | 17 | 4 | 3hp · 1Ø | 73 | 147 | 43.3L x 21.3W x 31.9H" |
